5XT

The L-Acoustics 5XT is an ultra-compact, passive 2-way coaxial loudspeaker designed for short-throw applications requiring minimal visual impact. It delivers studio-quality sound in a discreet form factor, making it ideal for front-fills, distributed systems, and architectural installations.

• Coaxial Design: 5" LF driver and 1" HF compression driver arranged coaxially for a single-point source, ensuring smooth off-axis response and consistent tonal balance
• Wide Coverage: 110° conical directivity provides uniform sound distribution, ideal for near-field applications
• Versatile Mounting: Equipped with a 3/8" insert for microphone stand mounting and two M6 inserts for ETR5 U-bracket, allowing flexible installation options

Frequency Response (-10 dB): 95 Hz – 20 kHz
Maximum SPL: 121 dB
Transducers: LF: 1 × 5" cone driver; HF: 1 × 1" diaphragm compression driver
Nominal Impedance: 16 Ω
Connectors: IN: 1 × 4-point speakON; LINK: 1 × 4-point speakON; IN/LINK: 2 × 2-point screw terminals
Cabinet Material: Premium grade Baltic birch plywood with steel grille and anti-corrosion coating
Finish Options: Dark grey brown Pantone 426 C; Pure white RAL 9010; Custom RAL colors on special order
Dimensions (H × W × D): 6.5" × 6.5" × 6.5" (165 × 165 × 165 mm); Weight: 7.7 lbs (3.5 kg)
